Otis 10.4" Standard PI
Our 10.4" Otis Standard PI provides a large, highly configurable display for lift position, direction, passenger information and messaging. The OMN104-ACX can display arrival arrows, priority messages and destination information, with graphics and layouts customised to complement the building or installation.
Designed specifically for Otis installations, the OMN104-ACX supports Otis RSL and EMS inputs and is suitable for car operating panels, car transoms, lobby or arrival applications and destination displays. It also supports USB updates, self-testing, passing chime output and automatic display blanking to help extend backlight life.
Engineered to suit Otis equipment.
Direct-fit indicators and interface cards built for Otis controllers and fixtures, driven over MICRO COMM for a clean modernisation.
Technical specification
Connect it to your Otis controller.
The wiring diagram details the connection to the Otis controller over MICRO COMM; mounting dimensions are given in the datasheet and dimensional drawing.
Stuck on a connection or signal type? Talk to technical support.
