1 Character 75mm Dot Matrix

1 Character 75mm Dot Matrix

EV130-XXXXX
Made to order · lead time on request

Our EV130-XXXXX provides large-format, single-character floor indication using a 75 mm LED dot matrix display. Alphanumeric and custom characters can be presented, allowing the indicator to accommodate different floor naming conventions whilst maintaining excellent passenger visibility.

Its 60 mm wide × 160 mm high configuration makes it particularly suited to applications requiring a large floor character where available panel width remains limited.

Request a quote
Documentation
PDFDatasheet↓PDFWiring diagram↓
Display1-character 75 mm LED dot matrix
IndicationPosition · direction · scrolling messages
Signal inputLatched · MICRO COMM
AudioPassing chime output
OverviewSpecificationsWiring & InstallationDocumentation

Crisp LED position indication.

A self-contained dot-matrix unit that drops into the existing fixture and reads the signals already on your controller: single digit with an arrow, or dual-digit floor designations.

Scrolling & rollover
Single digit with arrow or dual-digit floors.
Hall lantern option
Add directional landing indication.
Passing chime
Audible passing indication.
Direct fit
Self-contained; mounts to existing fixtures.

Technical specification

Display1-character 75 mm LED dot matrix
IndicationPosition · direction · scrolling messages
Signal inputLatched · MICRO COMM
AudioPassing chime output
MountingCar-OP, transom or hall
ApplicationModernisation

Connect it over MICRO COMM.

Terminal layouts and connection detail for the MICRO COMM input are in the wiring diagram. Cut-out, stud pattern and mounting dimensions are given in the datasheet and dimensional drawing.

PDFWiring diagramTerminal & connection detail · PDFDownload ↓

Stuck on a connection or signal type? Talk to technical support.

1 Character 75mm Dot Matrix wiring diagram

Everything you need to specify and fit.

PDFDatasheetFull technical datasheet: specifications, dimensions and ordering codes.↓
PDFWiring diagramConnection and terminal wiring for all supported signal types.↓
