3″ LED EXTENDED DESTINATION BLOCK

3″ LED EXTENDED DESTINATION BLOCK

MBOX
Made to order · lead time on request

Our MBOX-X combines arrival indication and destination information in a compact 3" LED display designed for destination-based lift systems. When a lift becomes available, the display illuminates white, changing to green for upward travel or red for downward travel whilst showing the assigned destination characters.

The unit connects directly to the MICRO COMM network and provides a 180° viewing angle, making it easy to identify the assigned lift from different positions within the lobby. It also includes an integrated speaker for arrival and destination tones, DIP-switch selectable programming and support for an optional destination voice card.

Request a quote
Documentation
PDFDatasheet↓PDFWiring diagram↓
Display3″ LED destination display
IndicationDestination · direction · arrows
Signal inputMICRO COMM
MountingCar & landing
OverviewSpecificationsWiring & InstallationDocumentation

Destination indication, car and landing.

Built for destination-control dispatching and driven over MICRO COMM, mounted to suit the car and landing fixtures you already have.

Destination dispatch
Shows the assigned car and direction.
Direction arrows
Clear directional indication.
MICRO COMM
Driven over the C.E. network.
Direct fit
Car and landing mounting.

Technical specification

Display3″ LED destination display
IndicationDestination · direction · arrows
Signal inputMICRO COMM
MountingCar & landing
ComplianceADA / DDA
ApplicationNew install

Connect it over MICRO COMM.

Terminal and connection detail for the MICRO COMM input is in the wiring diagram; cut-out and mounting dimensions are given in the datasheet and dimensional drawing.

PDFWiring diagramTerminal & connection detail · PDFDownload ↓

Stuck on a connection or signal type? Talk to technical support.

3″ LED EXTENDED DESTINATION BLOCK wiring diagram

Everything you need to specify and fit.

PDFDatasheetFull technical datasheet: specifications, dimensions and ordering codes.↓
PDFWiring diagramConnection and terminal wiring for all supported signal types.↓
PDFDimensional drawingCut-out, stud pattern and overall dimensions for fit-up.↓
