2.5″ LED EXTENDED DESTINATION ARROW

2.5″ LED EXTENDED DESTINATION ARROW

MPENDANT
Made to order · lead time on request

Our MPENDANT-XXX provides clear 2.5" LED destination indication for destination-based lift systems. Designed to connect directly to the MICRO COMM network, it is available in horizontal or vertical configurations with a choice of white, green, red, blue or amber LED characters.

Long-life solid-state LEDs provide a rated life of 100,000 hours, whilst the integrated speaker provides arrival and destination tones. Programming is DIP-switch selectable, with an optional destination voice card available where additional audible passenger information is required.

Request a quote
Documentation
PDFDatasheet↓PDFWiring diagram↓
Display2.5″ LED destination display
IndicationDestination · direction · arrows
Signal inputMICRO COMM
MountingCar & landing
OverviewSpecificationsWiring & InstallationDocumentation

Destination indication, car and landing.

Built for destination-control dispatching and driven over MICRO COMM, mounted to suit the car and landing fixtures you already have.

Destination dispatch
Shows the assigned car and direction.
Direction arrows
Clear directional indication.
MICRO COMM
Driven over the C.E. network.
Direct fit
Car and landing mounting.

Technical specification

Display2.5″ LED destination display
IndicationDestination · direction · arrows
Signal inputMICRO COMM
MountingCar & landing
ComplianceADA / DDA
ApplicationNew install

Connect it over MICRO COMM.

Terminal and connection detail for the MICRO COMM input is in the wiring diagram; cut-out and mounting dimensions are given in the datasheet and dimensional drawing.

PDFWiring diagramTerminal & connection detail · PDFDownload ↓

Stuck on a connection or signal type? Talk to technical support.

2.5″ LED EXTENDED DESTINATION ARROW wiring diagram

Everything you need to specify and fit.

PDFDatasheetFull technical datasheet: specifications, dimensions and ordering codes.↓
PDFWiring diagramConnection and terminal wiring for all supported signal types.↓
PDFDimensional drawingCut-out, stud pattern and overall dimensions for fit-up.↓
